Wire Tie Down Stud

Description   Wire Tie Down Stud   Wire Tie Down Stud is used to manage wires and organize your workspace or project! Easily install this device using the process of capacitor discharge (CD) stud welding. CD Stud Welding Capacitor Discharge (CD) Stud Welding is a semi-automatic arc welding process. During CD welding, the weld operator “shoots” small diameter fasteners onto thin gauge parent metal. The CD process operates on the principle of capacitor stored energy, which is instantaneously discharged by the equipment system through a special weld “timing” tip. Since the entire weld cycle occurs in several milliseconds, one can weld onto thin sheet metal without pronounced distortion, burn-through or discoloration. Additionally, CD welding permits stud welding of dissimilar metals. Nylon Wire Tie Mechanical Dimensions Inchmm Height0.3909.90 Length0.87522.22 Width0.62515.87 Slot Height0.0902.29 Slot Width0.3258.26 Nylon 6/6 Temperature Index Temperature Index Minimum ThicknessElectrical (°C)Mechanical w/o Impact (°C)Hot Wire Ignition (sec) 0.0281256511.8 0.0581258515.0 Nylon 6/6 NBS Smoke Generation Specific Optical Density Sample ThicknessUL FammabilityEnergy Sourceat Maximum Smoke Accumulationat 2 Minutes 1/16”94 V-2Radiant (2.5 watts/sq cm)130 1/16”94 V-2Radiant Plus Flaming Gas Jets261 Nylon 6/6 Properties PropertyASTM MethodTest ConditionUnitsNylon 6/6 Tensile StrengthD638 73° F; 50% RHkpsi11.2 Elongation at BreakD638 73° F; 50% RH%
